4K High-Definition Video Cable Assembly for Endoscopic Imaging Systems

Custom 4K UHD video cable assembly for endoscopic cameras

Medical-grade HDMI 2.0 cable for surgical imaging systems

4K High-Definition Video Cable Assembly for Endoscopic Imaging Systems

This 4K high-definition video cable assembly is specially designed for endoscopic imaging systems that require stable and high-resolution signal transmission.

Product Advantages:

High flexibility: Highly flexible, with a natural drape and no tangling
Resistant to bending: Withstands bending applications without loss of signal performance
Tensile strength: High-strength tensile handle design prevents damage during pulling
Water and Moisture Resistance: Liquid-molded silicone structure, suitable for liquid exposure environments
Hand Feel: Smooth and delicate surface of high-tear-resistant silicone sheath, non-stick to dust

Customization type: Customized

Inquiry Now

4K High-Definition Video Cable Assembly

A Professional Interconnection Solution for Endoscopic Imaging Systems

Performance Parameters

Structural Dimensions

Customized combination of high-frequency coaxial cable and multi-core electronic or twisted-pair differential signal cable (Based on customer's device electrical module design requirements)

Application Length

Standard black/gray/blue (based on customer's PT requirements)

Color and Appearance

Standard black/gray/blue (based on customer's PT requirements)

High-Frequency Withstand Voltage

Core withstand voltage (designed according to device electrical power requirements)

Bending Resistance

Designed according to device application scenario and lifespan requirements

Temperature Range

-40°C~200°C

Transmission Rating

HDMI 2.0/2.1/2.2 (as per customer requirements)

EMC Requirements

Compliant with medical device electromagnetic compatibility standards

Mating Cycles

>600 cycles (Reliability tested for repeated medical use)

Flame Retardant Rating

HB/V5/V2/V1/V0 (as per customer requirements)

Waterproof Rating

IP69K (as per customer requirements)

Environmental Rating

RoHS2.0/FDA/Biocompatible (as per customer requirements)

Lifespan

Single-use/Repeatable (as per customer requirements)

Packaging

Aseptic/Non-aseptic packaging/Anti-static packaging (As per customer requirements)

Validated Disinfection Methods

—— Completed by the device manufacturer

Method	Parameter/Condition
Cleaning	Ultrasonic & 75% alcohol cleaning
High Temperature	2bar ~ -134℃ high temperature
Gas & Chemical	Ethylene oxide & ozone
Irradiation	Electron beam (dose ≤ 25GY) irradiation
Plasma	Low temperature plasma (conc. ≤ 65% H2O2)

Product Application Fields

Widely used in endoscopic imaging systems and advanced medical diagnostic equipment.

Designed for Endoscopic Imaging Systems

🔌 Specifically engineered for use in endoscope imaging equipment and medical video systems.
📏 Meeting the strict requirements of medical imaging applications where signal stability and reliability are essential.
🧵 Integrated with various endoscopic cameras, imaging processors, and medical display systems.

FAQ

Get more information about our products. Have a quote today!

🔄 1. What is a 4K video cable assembly used for in endoscopic imaging systems?

4K video cable assembly is used to transmit high-resolution video signals between endoscope cameras, imaging processors, and medical display systems.

📶 2. What standards does the medical video cable assembly comply with?

Medical video cable assemblies are typically designed to meet strict medical equipment standards such as ISO quality management and IEC safety regulations.

🧬 3. Can the 4K video cable assembly be customized for medical devices?

Yes, most cable assemblies can be customized according to connector types, cable length, shielding structure, and system requirements.
