Power Control Cable Connector Assembly

Power Control Cable Connector Assembly

Name: Power Control Cable Connector Assembly
Availability: InStock

This power control cable connector assembly is designed for systems requiring stable power output, such as minimally invasive orthopedic instruments.
Product Advantages:
High Flexibility: Highly flexible and lightweight, with a natural drape and minimal tangling.
Bending Resistance: Can withstand bending applications without signal performance degradation.
Tensile Strength: High-strength tensile handle design prevents damage during pulling.
High-Frequency Applications: Stable and controllable power transmission.

Customization type: Customized

Inquiry Now

Power cable connector assemblies

Cutting and planing power system solutions

Performance Parameters

Structural Dimensions

Multi-core, multi-strand silver-plated copper foil wire, high-temperature resistant stranded cable + double-layer shielding + silicone sheath

Color and Appearance

Standard gray/blue (depending on customer requirements)

Length

Standard length: 3.3 meters (can be customized according to customer requirements)

Pressure Resistance

According to the electrical requirements of equipment operation

Temperature Range

According to the electrical requirements of equipment operation

Transmission Class

EMC Requirements

Meets the electromagnetic compatibility requirements for medical devices.

Bending Resistance

Designed according to the application scenarios and service life requirements of the equipment..

Flame Retardant Rating

According to customer requirements

Waterproof Rating

IP65 (as per customer requirements)

Environmental Protection Rating

RoHS 2.0 (As per customer requirements)

Mating Cycles

>1000 (Designed according to customer application requirements)

Lifespan

Repeatability (as per customer requirements)

Packaging Method

Individually packaged (as per customer requirements)

Validated Sterilization Methods

* Validation and completion in collaboration with customer equipment vendors based on specific clinical needs.

Method	Parameters/Conditions
Cleaning	Ultrasonic cleaning and 75% alcohol cleaning
High Temperature	2 bar at ~134°C
Gas and Chemicals	Ethylene oxide and ozone
Irradiation	Electron beam irradiation (dose ≤25 Gy)
Plasma	Low-temperature plasma (H2O2 concentration ≤ 65%)

Product Application Fields

It is widely used in orthopedic power systems and high-precision surgical cutting equipment.

Designed for Clinical Surgical Planers and Cutters

🔌 Integrated Medical Power Solutions: Specifically designed to facilitate high-speed data and power transmission between surgical shaver consoles and powered handpieces.
📏 Meets High-Load Cutting Demands: Ensures signal stability under high-speed loads of up to 60,000 RPM, guaranteeing continuous and latency-free power output throughout surgical procedures.
🧵 Compatible with Diverse Surgical Handpieces: Perfectly compatible with orthopedic arthroscopic shavers, ENT endoscopic cutters, and various other clinical surgical power control systems.

FAQ

Get more information about our products. Have a quote today!

🔄 1. How many autoclaving cycles can these power cables withstand?

Designed for high-turnover use, they are certified for repeated 2bar-134°C steam autoclaving without losing insulation integrity.

📶 2. Does the cable design prevent internal wire breakage from frequent pulling?

A: Yes. The reinforced internal braiding provides superior tensile drag resistance, protecting the core during rapid surgical maneuvers.

🧬 3. Are the connector housings completely waterproof and dustproof, suitable for operating room environments?

Absolutely. Our precision-sealed connectors prevent liquid and debris ingress, ensuring stable performance during operation.

Hot tags :

Power Control Cable Connector Assembly

Power cable connector assemblies

Performance Parameters

Validated Sterilization Methods

Product Application Fields

Designed for Clinical Surgical Planers and Cutters

FAQ

Shaver system handpiece cable

Reusable surgical motor cable
